Camera
Image Sensor
1/2.9” SONY Starvis CMOS Sensor
Frame Rate
1080p: 30 FPS
Resolution
1080p
Minimum Illumination
Color: 1 Lux
Black and White: 0.1 Lux
Effective Pixels
1920 (H) x 1080 (V)
Lens
Type
Motorized Vari-Focal Auto-Focusing
True Day / Night
Yes
Focal Range
2.8~12mm
Max. Aperture Ratio
ƒ1.4
DSP
DSP Version
EXHD 2.0
Display
Screen Size
32″
Contrast Ratio
3000:1
Response Time
6.5 ms
Resolution
1920 x 1080
Brightness
350 nit
Viewing Angle
178° / 178°
Aspect Ratio
16:9
Color Depth
16.7 million colors
Menu Control
Camera
Built-in Joystick
LCD
IR Remote and Button Pad
Connections
HDMI Input
1 HDMI Input
HD Video Output
1 BNC Output: EX-SDI 2.0, EX-SDI, HD-SDI Selectable
Analog Video Input
1 BNC Input – CVBS Only
SD Player
Video SD Memory
Analog Video Output
1 BNC Output: HD Analog – CVBS, A_HD, C_VI, T_VI Selectable
Power Requirements
Type
DC24V or AC110V
Power Consumption
DC24V: 45.58 Watts (1.9 Amps)
AC110V: 45.58 Watts (0.414 Amp)
Physical
Product Dimensions
29.25″ (W) x 19.625″ (H) x 3.1″ (D)
742.95mm (W) x 498.475mm (H) x 78.74mm (D)
Product Weight
29.05 lbs (13.17 kg)
Materials
Bezel
Powder-Coated Steel
LCD Protective Front
Glass
Mounting
Mounting Hole Pattern
VESA 100 & 100 x 200
Environmental
Operating Temperature
32° to 104° F (0° to 40° C)
Operating Humidity
0% to 90% RH
Standards
FCC
Part 15B, Class A
RoHS
Compliant
UL
Listed
What’s Included
4GB SD Card
2 Screws
DC24V Pigtail Connector
AC110V Power Cable
IR Remote
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
