Channels
Video Input
1 Channel
Input Type
HD-SDI (BNC)
Storage
Capacity
Up to 128GB SD Card (Includes 64GB SD Card)
Recording
Recording Frame Rate
1 ~ 25 FPS
Recording Mode
Continuous / Motion / Alarm / Manual
Recording Resolution
1920 x 1080p or 1280 x 720p
Video Codec
H.264
Recording Quality
High / Normal / Basic
File Type
.AVI
Display
Video Output (Digital)
1 HD-SDI (BNC) Output
1 HDMI Output
Video Output (Analog)
1 RCA (CVBS)
Connections
Alarm I/O
1 Inputs / 1 Output
Search
Playback Speed
x1, x2, x4, x8, x16, x32
Mode
Normal / Event
Power Requirements
Type
DC12V (1A)
Power Consumption
3 Watts
Physical
Product Dimensions
4.375″ (W) x 3″ (D) x 1″ (H)
111.125mm (W) x 76.2mm (D) x 25.4mm (H)
Product Weight
0.45 lbs (0.2 kg)
Environmental
Operating Temperature
32° to 122° F (0° to 50° C)
Operating Humidity
0% to 80% RH
What’s Included
64GB SDXC Card
HD-SDI (RG316) Video Cable, 14″
HDMI Video Cable, 28″
DC12V male to male power adapter cable, 16″
4 Screws for surface mounting
IR Remote
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
