Connections
Video Input/Output
1 BNC In / 1 BNC Out
Supported Digital Signals
EX-SDI, EX-SDI 2.0, & EX-SDI 4MP
Supported Analog Signals
Standard Analog/CVBS, CVI, TVI, & AHD
Surge Protection
Nominal Line Voltage
48VDC
Max Frequency
≤ 270MHz
Nominal Discharge Current (In) 8/20μs impulse - 10 times
20kA
Band Pass Range
270MHz
Max DC Operationg Voltage
60VDC
Insertion Loss
≤ 2dB
Max Discharge Current (Imax) 10/350μs impulse - 1 times
25kA
Max Current
750mA
Lightning Impulse Current (limp) 10/350μs impulse - 2 times
5kA
Clamping Voltage
20V
Physical
Product Dimensions
2.87” x .78” (L x Dia.)
73mm x 20mm (L xDia.)
Product Weight
0.1 lbs / 0.04 kg
Materials
Housing
Aluminum
Environmental
Operating Temperature
32° to 104° F (0° to 40° C)
Operating Humidity
5% to 85% RH
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
