Camera
Image Sensor
1/3″ SONY Exmor 1.3 Megapixel CMOS Sensor
Scanning System
2.1 Interlace
Shutter Speed
1/60 – 1/60,000 sec.
Resolution
1000 TVL
S/N Ratio
52dB
Effective Pixels
1305 (H) x 1049 (V)
Minimum Illumination
0.00001 Lux (Sens-Up x64)
Lens
Type
Vari-Focal
Focal Range
2.8~12mm
Max. Aperture Ratio
ƒ1.2
DSP
DSP Version
S8
Display
Screen Size
27″
Contrast Ratio
3000:1
Response Time
12 ms
Resolution
1920 x 1080
Brightness
300 nit
Viewing Angle
178° / 178°
Aspect Ratio
16:9
Color Depth
16.7 million colors
Menu Control
Camera
OSD Board inside hinged door
LCD
IR Remote and Button Pad
Connections
Composite Video Output
1 BNC Output
Power Requirements
Type
DC24V
Power Consumption
25 Watts (1.04 Amps)
Physical
Product Dimensions
24.375″ (W) x 16.375″ (H) x 3″ (D)
619.125mm (W) x 406.4mm (H) x 76.2mm (D)
Product Weight
15.6 lbs (7.07 kgs)
Materials
Bezel
Powder-Coated Steel
Mounting
Mounting Hole Pattern
VESA 75, 100 & 100 x 200
Environmental
Operating Temperature
32° to 104° F (0° to 40° C)
Operating Humidity
0% to 90% RH
Standards
FCC
Part 15B, Class A
RoHS
Compliant
UL
Listed
What’s Included
2 Screws
DC24V Pigtail Connector
IR Remote
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
Learn More
Technical Support
Free Lifetime Technical Support via Phone (1-800-549-6393)
Learn More
