CE-HVR16

16 CH Hybrid NVR

  • 16-Channel Hybrid Recording — Supports HD Analog, EX-SDI, and IP cameras
  • HD Analog Camera Inputs: HD-TVI, HD-CVI, AHD, and 960H, up to 4MP
  • EX-SDI Camera Inputs: HD-SDI, EX-SDI, and EX-SDI 2.0, up to 4MP
  • IP Camera Support: H.265 and H.264, up to 8MP at 30 FPS
  • Recording Performance:
    • 240 FPS at 4MP (15 FPS per channel)
    • 480 FPS at 2MP (30 FPS per channel)
  • Video Outputs: HDMI (4K) and RCA (CVBS) main monitor outputs
  • Spot Monitor Output: HD-SDI (1080p); RCA output can also be configured as an additional spot monitor
  • Flexible Management: Local GUI, web browser, AVMS Software, and CVMS Mobile App
  • Network Video: ONVIF Profile S and RTSP video output
  • Remote EX-SDI Camera Control: Adjust EX-SDI camera settings remotely using UCC on all 16 channels*
  • Audio: 16 audio inputs and 1 audio output
  • Alarms: 16 alarm inputs and 4 alarm outputs
  • Backup: Export recordings to USB or PC using AVMS remote software
  • Storage: Multiple HDD sizes and configurations available, up to 100TB of storage**
  • RAID Support: Configurable RAID storage options
  • Rack-Mountable: Includes rack-mount brackets
  • NDAA & TAA Compliant

*UCC (Up the Coax Control) requires an EX-SDI 2.0 DVR and camera equipped with UCC function. UCC allows camera adjustments (zoom in/out & adjust settings) to be made remotely through DVR.

Only authorized dealers can see pricing. Fill out our Dealer Application for access!
