Name: 32” LCD w/ Built-in Decoder (No Base)
SKU: CE-VT320-NVD

Display

Screen Size

32″

Contrast Ratio

3000:1

Response Time

6.5 ms

Resolution

1920 x 1080

Brightness

350 nit

Viewing Angle

178° x 178°

Aspect Ratio

16:9

Color Depth

16.7 million colors

Decoder Input

Codec

h.264 / h.265

Frame Rate

1~30 FPS

Camera Channels

Up to 16

Max Decoding Performance

8MP @ 60FPS (ex: 16ch @ 8M = 3.75fps per ch)

2M @ 360FPS (ex: 16ch @ 2M = 22.5fps per ch)

Resolution

352 x 240 ~ 3840 x 2160 (4K)

Color Depth

16.7 million colors

Decoder Output

Display Modes

Sequence and/or Multi-view

4×4 – 16 channels
3×3 Sequence (ch 1~9, 10~16)
2×2 Sequence (ch 1~4, 5~8, 9~12, 13~16)
1×1 Sequence (ch1~16)
Custom Sequence Layouts, up to 32

Custom Layouts

20+ Layout Options – Supports Corridor Video, Panoramic Video, Square (Fisheye) Video

Network

Network Speed

10/100/1000 Mbps

Supported Protocols

IPv4, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, NTP, UPnP, HTTP, HTTPS

Web Viewer

Google Chrome, Edge, Safari, Firefox

Menu Control

LCD

Buttons on Bezel

Decoder

Web Browser Only

Connections

Network Input

4 RJ45 Inputs

USB

1 USB Port (Monitor Firmware Updates)

Power Requirements

Type

DC24V

Power Consumption

48 Watts (2 Amp)

Power Supply

Power supply sold separately

Mounting

Mounting Hole Pattern

VESA 100×100 (M4)

Physical

Product Dimensions

28.6″ (W) x 17″ (H) x 2.34″ (D)

72.64cm x (W) x 43.18cm (H) x 5.94mm (D)

Product Weight

19.6 lbs (8.89 kgs)

Materials

Bezel

Steel

Mounting

Mounting Hole Pattern

VESA 100 (M4)

Environmental

Operating Temperature

14° to 122° F (-10° to 50° C)

Operating Humidity

0% to 90% RH

Standards

FCC

Part 15B, Class B

RoHS

Compliant

NDAA

Compliant

TAA

Compliant

What’s Included

DC24V Pigtail Connector

IR Remote

Warranty & Support

Warranty

3 Year Warranty w/1st Year Advance Replacement
Learn More

Technical Support

Free Lifetime Technical Support via Phone (1-800-549-6393)
Learn More

Is your LCD monitor designed for CCTV use?

CE-VT320-NVD Spec Sheet

Decoder (CE-NVD-B) Knowledge Base

Decoder (CE-NVD-B) Firmware
