Connections
Input
1 RJ45 Input (Data Only)
Output
1 RJ45 Output (Data and Power)
Power Requirements
PoE Standards
IEEE 802.3af
IEEE 802.3at
IEEE 802.3i 10BaseT
IEEE 802.3i 100BaseTX
IEEE 802.3x flow control
Input
AC 100-240V (50-60 Hz)
Output
DC48V – 15.4 Watts PoE
DC48V – 30 Watts PoE+
Power Consumption
35 Watts (max.)
Physical
Product Dimensions
5.7″ (L) x 2.24″ (W) x 1.58″ (H)
145mm (L) x 60mm (W) x 40mm (H)
Product Weight
0.7 lb (0.32 kg)
Materials
Housing
Plastic
Environmental
Operating Temperature
32° to 104° F (0° to 40° C)
Operating Humidity
10% to 90% RH
Standards
UL
Listed
FCC
Class A
What’s Included
AC110V Power Cable
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
Learn More
Technical Support
Free Lifetime Technical Support via Phone (1-800-549-6393)
Learn More
CE-PS102 Product Video
