Connections
Input
1 x RJ45 Input (Data Only)
Output
1 x RJ45 Output (Data and Power)
Data & Power
PoE Standards
IEEE 802.3bt Type 4 / 4PPoE / PoE++ (90 W)
IEEE 802.3at Type 2 / PoE+ (30 W)
IEEE 802.3af Type 1 / PoE (15.4 W)
IEEE 802.3i 10BaseT
IEEE 802.3i 100BaseTX
IEEE 802.3x flow control
Data Rate
10/100/1000 Mbps
Input
AC 100-240V (50-60 Hz)
Output
95W PoE++ (Type 4 – IEEE 802.3bt), 71.3W @ Powered Device (PD)
60W PoE++ (Type 3 – IEEE 802.3bt), 51W @ Powered Device (PD)
30W PoE+ (Type 2 – IEEE 802.3at), 25.5W @ Powered Device (PD)
15W PoE (Type 1 – IEEE 802.3af), 12.95W @ Powered Device (PD)
Power Consumption
95 Watts (max)
Physical
Product Dimensions
3.15″ (W) x 1.81 (H) x 7.02″ (D)
80mm (W) x 46mm (H) x 178.5mm (D)
Product Weight
1.4 lbs (0.635 kgs)
Materials
Housing
Steel
Environmental
Operating Temperature
32° to 104° F (0° to 40° C)
Operating Humidity
10% to 90% RH
Standards
UL
Listed
What’s Included
AC110V power cable
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
Learn More
Technical Support
Free Lifetime Technical Support via Phone (1-800-549-6393)
Learn More
CE-PS195 Spec Sheet
