Camera
Image Sensor
1/3″ 2 Megapixel Progressive Scan CMOS
Minimum Illumination
0.25 Lux
Video Orientation
Corridor Mode (portrait) 1080 x 1920
Resolution
Full HD 1080p
Video Codec
H.264 (MPEG-4 Part 10/AVC) Baseline
Shutter Speed
1/32500 – 1/5 sec.
Frame Rate
30 fps
Lens
Type
Fixed
Focal Range
2.8mm
Max. Aperture Ratio
ƒ2.0
Display
Screen Size
10″
Contrast Ratio
800:1
Response Time
25 ms
Resolution
800 x 1280
Brightness
350 nit
Viewing Angle
170° x 170°
Aspect Ratio
16:10
Color Depth
16.7 million colors
Menu Control
Camera
Web Browser (Chrome, Internet Explorer, Firefox, Safari)
LCD
IR Remote
Connections
Network
1 RJ45 Ethernet Port (10 / 100 Base-T PoE+)
Alarm Input
1 Terminal Block Input (+/-)
Alarm Output
1 Terminal Block Output (+/-)
Power Requirements
Type
DC24V or PoE+
Power Consumption
DC24V: 14 Watts
PoE+: 30 Watts
Physical
Product Dimensions
9.375” (W) x 7.6” (H) x 1.875” (D)
238.125mm (W) x 193mm (H) x 47.625mm (D)
Product Weight
3.5 lbs (1.58 kgs)
Materials
Bezel
Powder-Coated Steel
LCD Protective Front
Acrylic
Mounting
Mounting Hole Pattern
VESA 75 & 100
Environmental
Operating Temperature
32° to 104° F (0° to 40° C)
Operating Humidity
0% to 90% RH
Standards
FCC
Part 15B, Class B
RoHS
Compliant
UL
Listed
What’s Included
Torx Security Wrench
Torx Security Screw
DC24V Pigtail Connector
IR Remote w/ 2 x AAA Batteries
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
Learn More
Technical Support
Free Lifetime Technical Support via Phone (1-800-549-6393)
Learn More
