Name: 16 CH HD Analog &amp; Analog Encoder
SKU: CE-E16HDA

Channels

Video Input

16 Channels

Analog Input Type

TVI, AHD & CVBS

Input Resolution

8MP, 5MP, 4MP, 3MP, 2MP, 720p & CVBS

Network

Video Codec

h.264 (Baseline, Main, High) h.265 (Main), MJPEG

Bitrate Control

CBR or VBR

1st Stream: 512~8,000 kbps, 2nd Stream: 64~1,000 kbps

Protocols

IPv4, IPv6, TCP/IP, UDP/IP (Unicast, Multicast IGMP), UPnP, DNS, DHCP, RTP, RTSP, NTP, QoS, HTTP, HTTPS, SSH, SSL, SMTP

Streaming

2 individually configurable streams per camera

Standards

ONVIF Profile S

Audio Codec

G.711

Stream Resolution & Framerate

8MP @ 15 fps input: 1920×2160 ~ 352×240, max 8 fps

8MP @ 7.5 fps input: 2560×2160 ~ 352×240, max 4 fps

5MP @ 20 fps input: 1296×1944 ~ 352×240, max 10 fps

5MP @ 12 fps input: 2560×1944 ~ 352×240, max 6 fps

4MP @ 30 fps input: 1280×1440 ~ 352×240, max 15 fps

4MP @ 15 fps input: 2560×1440 ~ 352×240, max 7.5 fps

3MP @ 30 fps input: 1024×1536 ~ 352×240, max 15 fps

3MP @ 18 fps input: 2048×1536 ~ 352×240, max 9 fps

2MP @ 30 fps input: 1920×1080 ~ 352×240, max 15 fps

720p @ 30 fps input: 1280×720 ~ 352×240, max 30 fps

CVBS (NTSC/PAL): 960×480 ~ 352×240, max 30 fps

Display

Video Output (Main)

1 HDMI Output (up to 4k)

1 VGA Output

Video Output (Spot)

1 BNC Output (CVBS)

View Modes

Main Output: 1 / 4 / 6 / 8 / 9 / 16 / Sequence

Spot Output: Sequence (1 / 4)

Connections

Audio

4 RCA In / 1 RCA Out

PTZ / Keyboard

1 RS485 (+ / -)

Alarm

16 In / 1 Out

Ethernet

1 RJ-45 10/100 Mbps Ethernet

USB

2 USB Ports (mouse control & USB upgrade)

System

Operating System

Embedded Linux

User Control

USB Mouse, Remote Control, WebViewer

RS485 (PTZ) Protocols

Pelco-D/P, Mesa-Dome, D-Max,Fastraxll 2, Ganz PT v3, SCC 641/643a, Spd 3300, Multix, MRX 1000, WV cs850/csr604, PTC 400c/200, Takex, LPT-A100L, interM, Vitek, Lilin, Maxpro, VCL, Coaxitron, Vicon, Clinton-W, AD-SpeedDome

User Accounts

Multiple user accounts with permission levels based on group settings (Admin / Manager / User)

Up to 32 connected users

Coax Control Protocol

Pelco C, Coaxitron

Language

English, Korean, Japanese, Russian, Italian, French, German, Polish, Thai, Spanish, Taiwan, Dutch, Czech

Security

Password Protection

Basic or Enhanced (8 ~ 16 characters, must contain uppercase / lowercase letters, special characters, and numbers)

Password Terms

Off / Password Expired after 1 ~ 6 months

Auto User Logout

Off / On: 1 ~ 10 minutes of no user activity

Remote Viewing

Web Browser

Chrome, Edge, Firefox, Safari

Power Requirements

Type

DC12V

Power Supply

Includes Power DC12V (3A) Power Supply

Power Consumption

1.0A / 12W ± 10%

Physical

Product Dimensions

14.96” x 12.8” x 2.02” (Wx D x H)

380mm x 314.6m x 51.4mm (Wx D x H)

Product Weight

5.7 lbs (2.58 kgs)

Environmental

Operating Temperature

32° to 122° F (0° to 50° C)

Operating Humidity

0% to 80% RH

What’s Included

DC12V Power Supply

USB Mouse

IR Remote

Rack-mount brackets & screws

Warranty & Support

Warranty

3 Year Warranty w/1st Year Advance Replacement
