IP68 WEATHER RATED
Constant exposure to the elements is tough on any camera. Because the BZ series is IP68 weather rated, you no longer need to worry about adverse weather conditions.
EASY INSTALLATION
BZ bullet cameras can be mounted to a variety of Conduit Boxes. Use the mounting hook to affix the camera in place and free both hands for screw fastening.
HI INTENSITY IR LEDs
One IR LED on the new BZ Series Bullet outputs as much light as eight standard IR LEDs, and the focusing lenses help evenly distribute the infrared light.
EASY ADJUSTMENT
Say goodbye to cumbersome brackets that require multiple set screws. Achieve any angle and lock the BZ camera in place with just one screw.
AUTOFOCUS
All BZ cameras have Motorized Zoom & Auto Focus. Use the CE-REMOTE to set the focal length, and the autofocus lens will focus the scene to perfection.
DUAL VOLTAGE + RVM
All BZ Series Bullets are DC12V/AC24V and feature Rated Voltage Monitoring (RVM). The RVM LED indicator will illuminate to alert the installer of improper voltage.
Camera
Image Sensor
1/2.8” SONY Starvis 2.13 Megapixel CMOS Sensor
Scanning System
Progressive Scan
Minimum Illumination
Color: 0.01 Lux (Sens-Up x32)
Black and White: 0.001 Lux (Sens-Up x32)
Resolution
Full HD 1080p
S/N Ratio
More than 52dB (AGC Off)
Shutter Speed
1/30 – 1/30,000 sec. / AUTO
Effective Pixels
1945 (H) x 1097 (V)
Frame Rate
1080p: 30 FPS
720p: 60, 30 FPS
Lens
Type
Motorized Vari-Focal Autofocus
Field Of View
108° ~ 33° (Horizontal)
Focal Range
2.8~12mm
True Day/Night
Yes
Max. Aperture Ratio
ƒ1.4
IR LEDs
Quantity
4 High Intensity IR LEDs
DSP
DSP Version
EXHD 2.0
Menu Control
DIN Port
For use with CE-REMOTE (*CE-REMOTE required for Zoom/Focus Adjustments)
UCC
UCC allows camera adjustments (zoom/focus & OSD settings) to be made remotely through a UCC equpped DVR channel
Connections
HD Video Output
1 BNC Output (Black & Gold):
EX-SDI 2.0, EX-SDI, HD-SDI Selectable
Analog Video Output
1 BNC Output (Green & Silver):
CVBS (1,000 TVL), A_HD, C_VI, T_VI Selectable
Remote Control Input
1 DIN Input
Power Requirements
Type
DC12V and AC24V
Power Consumption
DC12V: 220mA Max: 1,020mA ±10% (IRs On + Zoom/Focus)
AC24V: 120mA Max: 450mA ±10% (IRs On + Zoom/Focus)
Physical
Product Dimensions
9.25″ (L) x 5.25″ (H)
234.95mm (L) x 133.35mm (H)
Product Weight
2.35 lbs (1065.942 g)
Materials
Housing
Aluminum
Environmental
Weather Rating
IP68
Operating Temperature
-40° to 122° F (-40° to 50° C)
Operating Humidity
0% to 95% RH
What’s Included
Mounting Plate
4 Phillips Screws (M5x25)
4 Allen Bolts (M4x8)
4 Plastic Washers
4 Drywall Anchors
Foam Gasket
3mm Allen Wrench
5mm Allen Wrench
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
