Camera
Image Sensor
1/2.8″ SONY Starvis 2.13 Megapixel CMOS Sensor
Scanning System
Progressive Scan
Minimum Illumination
0.001 Lux
Resolution
1080p
S/N Ratio
More than 52dB (AGC Off)
Shutter Speed
1/30 – 1/60,000 sec. / AUTO
Effective Pixels
1944 (H) x 1092 (V)
Frame Rate
1080p: 30 FPS
720p: 30 FPS
Lens
Type
Motorized Vari-Focal Autofocus
Field Of View
114.2° ~ 54.7° (Horizontal)
Focal Range
2.8~8mm
Max. Aperture Ratio
ƒ1.4
IR LEDs
Quantity
2 High Intensity IR LEDs
DSP
DSP Version
EXHD Lite 2.0
Menu Control
Joystick
Located on Cable
UCC
Allows camera adjustments (zoom/focus & OSD settings) to be made remotely through a UCC equipped DVR channel
Connections
HD Video Output
1 BNC Output (Black & Silver)
EX-SDI 2.0, EX-SDI, HD-SDI Selectable
Analog Video Output
1 BNC Output (Yellow & Silver)
CVBS (1,000 TVL), A_HD, C_VI, T_VI Selectable
Power Requirements
Type
DC12V
Power Consumption
DC12V: 0.45 Amps (450 mA) ±10% max.
Physical
Product Dimensions
6.12” x 2.63” x 2.59”
155.5mm x 67mm x 66mm
Product Weight
0.85 lbs (385 g)
Materials
Housing
Aluminum (camera body), Plastic (mounting plate)
Environmental
Weather Rating
IP68
Operating Temperature
-20°F to 122°F (-28°C to 50°C)
Operating Humidity
0% to 90% RH
What’s Included
3 Phillips Screws
3 Drywall Anchors
DC12V Pigtail/Barrel Plug Adapter
3mm Allen Wrench
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
Learn More
Technical Support
Free Lifetime Technical Support via Phone (1-800-549-6393)
Learn More
