Display
Screen Size
15.7″
Contrast Ratio
1000:1
Response Time
8 ms
Resolution
960 x 960
Brightness
700 nit
Viewing Angle
89° x 89° x 89° x 89°
Aspect Ratio
1:1
Color Depth
16.7 million colors
Camera
Image Sensor
1/2.8” SONY Starvis 2.1 Megapixel CMOS Image Sensor
Minimum Illumination
0.2 Lux (Color) / 0.04 Lux (B&W)
Lens
3.6mm (ƒ1.6)
Shutter Speed
1/4 – 1/10,000 sec.
Field of View
84° (Hori.) / 47.8° (Vert.) / 96.4° (Diag.)
Video
Video Codec
H.264, H.265, and Motion JPEG
Bitrate Control
CBR, VBR, or VBR+
1st Stream: 512~10,000 kbps
2nd & 3rd Stream: 512~8,000 kbps
Resolution
1920×1080 (Full HD 1080p) ~ 640×360
Streaming
3 individually configurable streams
Frame Rate
1~30 fps
Edge Storage
1 MicroSD Card slot, 256GB max recommended
Network
Supported Protocols
IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, SMTP, FTP, UPnP, HTTP
Web Viewer
Google Chrome, Edge, Firefox, Safari
Stream Method
Unicast / Multicast
Standards
ONVIF Profile S
Menu Control
Camera
Web Browser (Chrome, Edge, Firefox, Safari)
LCD
IR Remote
Connections
Network
1 RJ45 Ethernet Port
Power Requirements
Type
DC24V
Power Consumption
65 Watts / 2.71 Amps
Physical
Product Dimensions
20.625″ (W) x 20.625″ (H) x 2.67″ (D)
523.875mm (W) x 523.875mm (H) x 67.8mm (D)
Product Weight
17.8 lbs (8.07 kgs)
Materials
Bezel
Powder-Coated Steel
LCD Protective Front
Acrylic
Mounting
Mounting Hole Pattern
VESA 100×100 (M4)
Environmental
Operating Temperature
32° to 104° F (0° to 40° C)
Operating Humidity
0% to 90% Non-condensing
Standards
FCC
Part 15B, Class B
RoHS
Compliant
NDAA
Compliant
TAA
Compliant
What’s Included
2 Screws
DC24V Pigtail Connector
IR Remote
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
