Display
Screen Size
43″
Contrast Ratio
4000:1
Response Time
8 ms
Resolution
1920 x 1080
Brightness
500 nit
Viewing Angle
178° x 178° (89° x 89° x 89° x 89°)
Aspect Ratio
16:9
Color Depth
16.7M (8 BIT)
Camera
Image Sensor
1/2.8” SONY Starvis 2.1 Megapixel CMOS Image Sensor
Minimum Illumination
0.2 Lux (Color) / 0.04 Lux (B&W)
Lens
3.6mm (ƒ1.6)
Shutter Speed
1/4 – 1/10,000 sec.
Field of View
84° (Hori.) / 47.8° (Vert.) / 96.4° (Diag.)
Video
Video Codec
H.264, H.265, and Motion JPEG
Bitrate Control
CBR, VBR, or VBR+
1st Stream: 512~10,000 kbps
2nd & 3rd Stream: 512~8,000 kbps
Resolution
1920×1080 (Full HD 1080p) ~ 640×360
Streaming
3 individually configurable streams
Frame Rate
1~30 fps
Storage
MicroSD Card (up to 1TB) *card not included
Network
Supported Protocols
IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, SMTP, FTP, UPnP, HTTP, SSL/TLS
Web Viewer
Google Chrome, Edge, Firefox, Safari (MJPEG live view only)
Stream Method
Unicast / Multicast
Standards
ONVIF Profile S
Menu Control
Camera
Web Browser (Chrome, Edge, Firefox, Safari)
LCD
IR Remote or Controls on Back
Connections
Network
1 RJ45 Ethernet Port
Power Requirements
Type
DC24V (4-pin DIN connector) or AC110V
Power Consumption
58 Watts (2.42 Amps) ±10%
Physical
Product Dimensions
38″ (W) x 24″ (H) x 3″ (D)
96.52cm (W) x 60.96cm (H) x 7.62cm (D)
Product Weight
38.6 lbs (17.5 kgs)
Materials
Bezel
Steel (Powder-Coated)
Mounting
Mounting Hole Pattern
VESA 100, 100×200 (M4), 200×200 (M6)
Environmental
Operating Temperature
32° to 104° F (0° to 40° C)
Operating Humidity
0% to 90% Non-condensing
Standards
FCC
Part 15B, Class B
NDAA
Compliant
RoHS
Compliant
TAA
Compliant
ONVIF
Profile S Conformant
What’s Included
2 Screws
DC24V 4-PIN Pigtail Adapter Cable
AC110V Power Cable
IR Remote
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
Learn More
Technical Support
Free Lifetime Technical Support via Phone (1-800-549-6393)
Learn More
