Marketing meets Loss Prevention.
The Next Generation of Public View Monitors
It’s both digital signage and an active theft deterrent seamlessly integrated into a single device. By creating a new, unified hardware and software platform, we’ve created an entirely new product category that bridges the gap between marketing and loss prevention. This device has the unique ability to have a positive impact on a retailer’s bottom line by both reducing loss due to theft and increasing product awareness.
Camera
Image Sensor
1/2.8” SONY Starvis 2.1 Megapixel CMOS Image Sensor
Minimum Illumination
0.2 Lux (Color) / 0.04 Lux (B&W)
Resolution
Full HD 1080p
Video Codec
H.264, H.265, and Motion JPEG
Shutter Speed
1/4 – 1/10,000 sec.
Frame Rate
1~30 fps
Lens
Type
Fixed
Focal Range
2.8mm
Max. Aperture Ratio
ƒ1.6
Display
Screen Size
13″
Contrast Ratio
800:1
Response Time
25 ms
Resolution
800 x 1280
Brightness
800 nit
Viewing Angle
89° x 89° x 89° x 89°
Aspect Ratio
16:10
Color Depth
16.7 million colors
Menu Control
Camera
Web Browser (Chrome, Firefox, Safari)
LCD
IR Remote
Connections
Camera Output
1 RJ45 Ethernet Port
Network
1 RJ45 Gigabit Ethernet Port
Built-in Wifi (2.4GHz)
Alarm Input
1 Terminal Block Input (+/-)
1 Push-Button on Front Bezel
System Requirements
Built-in Digital Signage Player
Registered Clinton Connect account
WiFi or Ethernet network w/ Internet access (minimum 2 Mbps download speed)
Digital Signage Software
Windows PC or Mac w/ internet access
Google Chrome, Microsoft Edge or Safari internet browser
Power Requirements
Type
DC24V
Power Consumption
DC24V: 19.2 Watts (0.8 Amps)
Physical
Product Dimensions
7.65” (W) x 13.97” (H) x 1.57” (D)
194.31mm (W) x 363.47mm (H) x 39.37mm (D)
Product Weight
5.45 lbs (2.47 kgs)
Materials
Bezel
Powder-Coated Steel
LCD Protective Front
Acrylic
Mounting
Mounting Hole Pattern
VESA 75 & 100
Environmental
Operating Temperature
32° to 104° F (0° to 40° C)
Operating Humidity
0% to 90% RH
Standards
FCC
Part 15B, Class B
RoHS
Compliant
UL
Listed
What’s Included
Torx Security Wrench
Torx Security Screw
DC24V Pigtail Connector
IR Remote w/ 2 x AAA Batteries
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
Learn More
Technical Support
Free Lifetime Technical Support via Phone (1-800-549-6393)
Learn More
