Display
Screen Size
23.8″
Brightness
250 nit
Response Time
10 ms
Resolution
1920 x 1080
Contrast Ratio
3000:1
Viewing Angle
178° / 178°
Aspect Ratio
16:9
Color Depth
16.7 million colors
Menu Control
LCD
Buttons on bezel
Connections
Composite Video Input
1 BNC Input
Composite Video Output
1 BNC Output
VGA Video Input
1 VGA Input
HDMI Video Input
1 HDMI Input (1920x1080p max)
Power Requirements
Type
DC24V
Power Consumption
0.8A / 19.2Watts
Physical
Product Dimensions
22.62″ (W) x 13.45″ (H) x 2.5″ (D)
574.55mm (W) x 341.63mm (H) x 63.5mm (D)
Product Weight
11.1 lbs (5.03 kgs)
Materials
Bezel
Plastic
Mounting
Mounting Hole Pattern
VESA 100 & 100 x 200
Environmental
Operating Temperature
14° to 122° F (-10° to 50° C)
Operating Humidity
0% to 90% RH
Standards
FCC
Part 15B, Class B
RoHS
Compliant
TÜV SÜD
Compliant
What’s Included
DC24V Pigtail Connector
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
Learn More
Technical Support
Free Lifetime Technical Support via Phone (1-800-549-6393)
Learn More
CE-VT240-NB
