Camera
Image Sensor
1/2.9″ 2 Megapixel Progressive Scan CMOS
Minimum Illumination
0.2 Lux (Color) / 0.04 Lux (B&W)
Resolution
1920×1080 (Full HD 1080p) to 320×240
Video Codec
h.264 (MPEG-4 Part 10/AVC) Main and High Profiles
h.265 (MPEG-H Part 2/HEVC) Main Profile
Motion JPEG
Shutter Speed
1/32500 – 1/5 sec.
Frame Rate
30 fps
Lens
Type
Fixed
Field of View
102° (Horizontal) / 55° (Vertical)
Focal Range
3.1mm
Max. Aperture Ratio
ƒ2.0
Display
Screen Size
27″
Contrast Ratio
3000:1
Response Time
6.5 ms
Resolution
1920 x 1080
Brightness
300 nit
Viewing Angle
178° / 178°
Aspect Ratio
16:9
Color Depth
16.7 million colors
Menu Control
Camera
Web Browser (Chrome, Internet Explorer, Firefox, Safari)
LCD
IR Remote and Button Pad
Connections
HDMI Input
1 HDMI Input
Composite Video Output
1 BNC Output
SD Player
Video SD Memory
Network
1 RJ45 Ethernet Port
Power Requirements
Type
DC24V for Camera and Monitor; Optional PoE for Camera
Power Consumption
DC24V: 45 Watts (1.875 Amps)
Physical
Product Dimensions
25″ (W) x 17.25″ (H) x 3″ (D)
635mm (W) x 438.15mm (H) x 76.2mm (D)
Product Weight
19.5 lbs (8.845 kg)
Materials
Bezel
Powder-Coated Steel
LCD Protective Front
Low-Glare Tempered Glass
Mounting
Mounting Hole Pattern
VESA 75, 100 & 100 x 200
Environmental
Operating Temperature
32° to 104° F (0° to 40° C)
Operating Humidity
0% to 90% RH
Standards
FCC
Part 15B, Class B
RoHS
Compliant
UL
Listed
What’s Included
4GB SD Card
2 Screws
DC24V Pigtail Connector
IR Remote
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
Learn More
Technical Support
Free Lifetime Technical Support via Phone (1-800-549-6393)
Learn More
