Display
Screen Size
32″
Contrast Ratio
4000:1
Response Time
6.5 ms
Resolution
1920 x 1080
Brightness
400 nit
Viewing Angle
178° x 178°
Aspect Ratio
16:9
Color Depth
16.7 million colors
Camera
Image Sensor
1/3” Progressive Scan RGB CMOS Image Sensor
Minimum Illumination
0.2 Lux (Color)
Lens
2.8mm (ƒ2.0)
Shutter Speed
1/30 – 1/32,500 sec.
Field of View
111° (Hori.) / 61° (Vert.)
Video
Video Codec
H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles
Motion JPEG
Streaming
Multiple, individually configurable streams in H.264 and Motion JPEG, Axis Zipstream technology in H.264, Controllable frame rate and bandwidth
Resolution
1920×1080 (Full HD 1080p) ~ 160×90
Frame Rate
1~30 fps
Network
Security
IP address filtering, HTTPS encryption, IEEE 802.1x (EAP-TLS) network access control, multi-level user, signed video, Axis Edge Vault, Axis device ID, secure keystore (CC EAL4 certified)
Network Protocols
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, RTCP, DHCP, SSH, CDP, MQTT, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
Menu Control
Camera
Web Browser (Chrome, Edge, Firefox, Safari)
LCD
IR Remote or Controls on Back
Connections
Network
1 RJ45 Ethernet Port
Alarm Input
1 +/- Alarm Input
Power Requirements
Type
DC24V
Power Consumption
55 Watts (2.5 Amps)
Physical
Product Dimensions
28.5″ (W) x 18.375″ (H) x 2.125″ (D)
72.4cm (W) x 46.67cm (H) x 5.39cm (D)
Product Weight
21.8 lbs (9.63 kgs)
Materials
Bezel
Powder-Coated Steel
Mounting
Mounting Hole Pattern
VESA 100×100 (M4)
Environmental
Operating Temperature
32° to 104° F (0° to 40° C)
Operating Humidity
0% to 90% Non-condensing
Standards
FCC
Part 15B, Class B
NDAA
Compliant
RoHS
Compliant
TAA
Compliant
UL
Listed
What’s Included
2 Screws
24 Volt 4-Pin DIN to Pigtail Adapter Cable
IR Remote
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
Learn More
Technical Support
Free Lifetime Technical Support via Phone (1-800-549-6393)
Learn More
